Soil gas sampling system (BLPS 404) with 4 measuring channels. With the BLPS 404 you can perform reproducible soil gas sampling. Measurement channels: CO2, CH4, H2S and O2. Application: exploration of contaminated sites, evaluation of landfills

he Gas Chromatograph PID uses a Photoionization Detector (PID) to selectively detect volatile halogenated and aromatic hydrocarbons (eg BTEX). Compounds can be detected that have an ionization potential less than or equal to that of the lamp used. A lamp with 10.6 eV is incorporated. The temperature control is isothermal at 40 ° C, 60 ° C or 120 ° C. It can be used for continuous operation 24 hours a day, 7 days a week.

Application: emission and immission measurements, industry

The water sampling system (WSS3) allows automatic headspace analysis online. The water sample is processed using the headspace method. Compounds in the water are converted to the gas phase and are automatically transferred to the connected GC and then analyzed.

Application: Environment, industry, sewage treatment plants, drinking water systems.

The Measurement Point Switch (MSU) is combined with the Gas Chromatograph and / or the WSS3 to increase the number of measurement points that can be sampled in continuous operation.

In addition, we can provide Chromium IV (air) measuring device and quick test for eg Redox, pH, temperature and conductivity in water.

All devices are housed in our spacious air-conditioned mobile container. Our equipment is perfectly coordinated and can be used as a whole in the field. But it is also possible to use individual devices.
